Accessories
Fixed Base
Rotatable Field Base
Rotating Base
For use where mast is not required to be rotatable or where Omni-directional antennas are to be used.
Allows masts to be fitted horizontally & then swung vertical. Spike to secure. Fitted with clamp brake.
For use where full mast rotation is required whether internally / externally vehicle mounted, wall or shelter mounted. Ball design accommodates misalignment. Fitted with clamp brake.
Also available is a rotatable base with a static air entry point.
Also available is a rotatable base with a static air entry point.
Upper Mounting Bracket
Saddle Mounting Clamps
Lower Bracket
Allows the mast to rotate. When a mast is externally vehicle or shelter mounted, this bracket supports the mast at its upper end. The bracket has a PTFE lining. Lower end of the mast should be fitted with a fixed or rotatable base.
Normally used in pairs, the saddle clamp assembly fits the base section of the mast, facilitating mounting for installations where frequent mast removal is required. Made from light alloy with steel fittings.
Designed to receive either the fixed or rotatable base depending on the mast application.
Vehicle Mount
Universal Collar
Universal Tripod
Provides a quick and easy deployment from the tow bar of a vehicle, ideal for vehicle-based projects where there will be multiple deployments in a short timeframe. Comes with a heavy duty transit case as standard.
The universal collar is a multi-purpose accessory that allows the mast to integrate into a number of other accessories. These include the Vehicle Mount, Universal Tripod and Wall Bracket. The Universal Collar suits masts with a 3.5" diameter base tube or smaller.
A lighter, cost effective, and versatile deployment option that utilises the universal collar system. This tripod is for masts with a 3.5" base tube diameter or less, and is suitable for both short and long deployments.
Tilt Unit
Heavy Duty Transit Cases
Guy Rope Assemblies
This unit is predominantly used on trailers where the retracted height of the mast used is too high. The Tilt Unit allows the mast to be lowered and stored in the horizontal position.
Customised accessories are available to mount our masts and equipment onto our masts. Please contact us to discuss your project.
Essential accessories for improved stability, guy rope assemblies come in a variety of lengths, colours and strengths.
Roof Bearings
Customised Accessories
Field Legs
Provides a rotatable, weatherproof bearing where the mast passes through the vehicle roof skin. Used to support internally mounted masts whether on fixed or rotatable bases.
Customised accessories are available to mount our masts and equipment onto our masts (Guy Anchor Block Assy shown). Please contact us to discuss your project.
This assembly consists of four adjustable legs, two stepped and two plain, which connect to Mounting Collar. Four spikes, a base and a wheel handle are included.
