European Assembled Masts
STX & ST Masts
THE SMALL MAST WITH RUGGED CONSTRUCTION
The ST series of telescopic masts has a 3" base tube and is similar to the PT series, though smaller in diameter and headload capacity. Turnable after extension. Ideal for vehicle mounted applications where the headload to be lifted is neither heavy nor bulky.
| STX series | Heights (metres) | Headload | ||
|---|---|---|---|---|
| Model | Extended | Retracted | kg | |
| 3 tube section masts | ||||
| STX25-3-TC | 2.56 | 1.47 | 20.0 | |
| STX35-3-TC | 3.56 | 1.57 | 20.0 | |
| STX45-3-TC | 4.56 | 1.97 | 20.0 | |
| STX55-3-TC | 5.56 | 2.42 | 20.0 | |
| STX65-3-TC | 6.56 | 2.82 | 20.0 | |
| STX75-3-TC | 7.56 | 3.12 | 20.0 | |
| STX90-3-TC | 9.06 | 3.72 | 20.0 | |
| ST series | Heights (metres) | Headload | ||
| Model | Extended | Retracted | kg | |
| 4 tube section masts | ||||
| ST45-4-TC | 4.55 | 1.61 | 15.0 | |
| ST55-4-TC | 5.55 | 1.86 | 12.0 | |
| ST65-4-TC | 6.55 | 2.14 | 10.0 | |
| ST75-4-TC | 7.55 | 2.41 | 10.0 | |
| ST90-4-TC | 9.05 | 2.82 | 7.5.0 | |
| 5 tube section masts | ||||
| ST1-5-TC | 7.68 | 2.15 | 9.0 | |
| ST2-5-TC | 9.20 | 2.48 | 6.5 | |
| ST3-5-TC | 6.16 | 1.82 | 9.0 | |
| ST4-5-TC | 4.93 | 1.54 | 9.0 | |
